TECHNICAL SPECIFICATIONS
MODEL UDD-24-48 UDD-24-60 UDD-24-72
Doors 2 2 3
Temperature range 33º F ~ 38ºF
(0ºC ~ 3ºC)
33º F ~ 38ºF
(0ºC ~ 3ºC)
33º F ~ 38ºF
(0ºC ~ 3ºC)
Shelves 4 4 6
Cabinet dimensions
(L x D x H)
48.8 x 24.4 x 36.2(in)
1240 x 620 x 920(mm)
60.8 x 24.4 x 36.2(in)
1544 x 620 x 920(mm)
72.8 x 24.4 x 36.2(in)
1848 x 620 x 920(mm)
Compressor HP 1/3+ 1/3+ 1/3+
Voltage 115V/60Hz
230-240V/50Hz
115V/60Hz
230-240V/50Hz
115V/60Hz
230-240V/50Hz
Amps 6.4 6.4 7.4
NEMA Config 5-15P 5-15P 5-15P
Gross Weight 315lps/143 Kgs 380lps/173 Kgs 410lps/186 Kgs
