| TECHNICAL SPECIFICATIONS | |||
| MODEL | UBB-24-48F | UDD-24-60F | UBB-24-72F |
| Doors | 2 | 2 | 3 |
| Temperature range | 33º F ~ 38ºF (0ºC ~ 3ºC) |
33º F ~ 38ºF (0ºC ~ 3ºC) |
33º F ~ 38ºF (0ºC ~ 3ºC) |
| Capacity | 11.8(cu.ft) 335(L) |
15.8(cu.ft) 446(L) |
19.6(cu.ft) 556(L) |
| Shelves | 4 | 4 | 6 |
| Cabinet dimensions (L x D x H) |
48.8 x 24.4 x 36.2(in) 1240 x 620 x 920(mm) |
60.8 x 24.4 x 36.2(in) 1544 x 620 x 920(mm) |
72.8 x 24.4 x 36.2(in) 1848 x 620 x 920(mm) |
| Compressor HP | 1/3+ | 1/3+ | 1/3+ |
| Voltage | 115V/60Hz 230-240V/50Hz |
115V/60Hz 230-240V/50Hz |
115V/60Hz 230-240V/50Hz |
| Amps | 6.4 | 6.4 | 7.4 |
| NEMA Config | 5-15P | 5-15P | 5-15P |
| Gross Weight | 315lps/143 Kgs | 380lps/173 Kgs | 410lps/186 Kgs |
